Low Price PLC Controlled Multifunction Metal C Profile Gauge Keel Channel Frame Light Steel Angle Roll Forming Machine for Sale

Ask Lasest Price
Supply Ability :	10 Sets/Month
Payment Terms :	L/C, T/T, D/P, Western Union, Paypal, Money Gram
Certification :	CE, RoHS, GS, ISO9001, SGS

Add to Cart

Product Details
Company Profile

Low Price PLC Controlled Multifunction Metal C Profile Gauge Keel Channel Frame Light Steel Angle Roll Forming Machine for Sale

Product Description

Customer Question & Answer

Ask something for more details (0)

Low Price PLC Controlled Multifunction Metal C Profile Gauge Keel Channel Frame Light Steel Angle Roll Forming Machine For Sale

Low Price PLC Controlled Multifunction Metal C Profile Gauge Keel Channel Frame Light Steel Angle Roll Forming Machine for Sale

Specifications

Thickness	Max1mm
Installation Size	6.5M0.9M1.4M
Under Frame	square Pipe Welded,
Working Table	25mm Steel Plate with precision processing
Feeding System	galvanized roller flatting with adjustment
Gateway Thickness	35-40mm
Gateway Height	383mm
Double Bearing Inside with inject oil, Gateway fixed on the platform
Roller Station	14 Steps
Roller Shaft	60mm with key-way
Driving Motor	5.5KW
Brand	Lichao
Quantity	1 Unit
Cutting System	Structure with 23mm steel plate
Cutting Mold	Cr12Mov
Hydraulic Pump Station	5.5KW
Transmission Chain	1.2 Inch.
Production Speed	0-15m/min

ABOUT US:
Low Price PLC Controlled Multifunction Metal C Profile Gauge Keel Channel Frame Light Steel Angle Roll Forming Machine for Sale

More Products for Your Choose:
Low Price PLC Controlled Multifunction Metal C Profile Gauge Keel Channel Frame Light Steel Angle Roll Forming Machine for Sale

FAQ:
1. How long the machine could be made?- Normally speaking, light gauge steel frame machine could
be made within 45 working days. If you need machines in a hurry, we can make it for you
less than a month.
2. How to visit your company?
-a.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour),
then we can pick up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5
hours), then we can
pick up you.
3. Do you have after sales support?
-Yes, we are happy to give advice and we also have skilled technicians available across the
world.We need your machines running in order to keep your business running.
