Automatic Change Size C Purlin Roll Forming Machine C100-300 Light
Steel Frame Roll Forming Machine
The C shaped purlines formed by C shape roll forming machine have
excellent anti-bending property and are easy to install. They are
widely used as the supporter of roof and wall in large-scale and
mid-scale construction, such as factory, warehouse, garage,
exhibition center, cinema, theatre, garden and so on.
Technical parameters :
1. | Configurations | Manual Uncoiler, Guiding Platform, 9 Shaft Strip Leveler, Main
Machine Of Roll Forming, Hydraulic Motor, Pre-Punching
Device,Pre-Cutting Device, Hydraulic Station, PLC Control,
Supporter Table. |
2. | Control System | PLC Inverter Encoder Touch Screen |
3. | Main Frame | 400mm H-Beam |
4. | Total Power | 22 kw |
5. | Power Supply | 380V, 3-Phase,50Hz |
6. | Forming Speed | 12-24m/min |
7. | Roll Station | 18 stands |
8. | Roller Diameter | 80mm |
9. | Effective Width | 80-300mm |
10. | Feeding Thickness | 1.5-3.0mm |
11. | Backboard Thickness | 20mm |
12. | Cutter Standard | GCr12 |
13. | Roller Standard | Gcr15# |
14. | Overall Size | About 8500×1000×1400mm |
15. | Total Weight | About 10T |
16. | Custom | According to customer's requirements |
NOTE: All technical parameters can be changed according to user s
need, and only as a reference.
2.Automatic Change Size C Purlin Roll Forming Machine C100-300 Light
Steel Frame Roll Forming Machine Components specification
(1) Manual Uncoiler
Max.Capacity:5T
(2)Pre- Cutting Device& Pre-Punching Device
It adopts hydraulic motor drive and PLC computer-controlled to fix
length of die cutting.
Cutting length tolerance:±2mm
Material:GCr12 with quenched treatment 60-62°C
(3)Hydraulic System
Match equipment: Electro motor, a set of hydraulic tank, a set of
hydraulic oil pump, and electromagnetic valve.
Power: 22 KW
(4)Control System
It adopts PLC control system, Color Touch Screen; the target length
can be adjusted by it.
Computed mode: automatic or manual
(5)Encoder
The counter gauges length, and modulates pulses.
(6)Simple Stack
It is used for loading the formed plate.
Photo for Automatic Change Size C Purlin Roll Forming Machine
C100-300 Light Steel Frame Roll Forming Machine:
Exhibitions Photos:
ABOUT US:CANGZHOU NEXUS MACHINERY CO., LTD Company is in producing sandwich
panel line all kinds of roll forming machines, such as glazed tile
roll forming machine, roof/wall panel roll forming machine, double
layer roll forming machine, Full-Automatic C and Z Purlin Roll
Forming Machine, floor deck roll forming machine, highway guardrail
machine, dust shield machine, ridge cap machine, roll shutter door
machine, uncoiling & leveling & slitting & recoiling line, all
kinds of decoilers and stackers, and many other related equipments
like shear, punch, slitter, leveler, crimping curving, bending and
so on,different sizes roofing sheet,PPGI/GI ,Alu-Zinc steel coils
,Galvanized steel coils ,Galvanized steel sheet ,Galvalume steel
coils/sheet ,cold/hot rolled sheet/cols , professional service and
favorable price , satisfied with the quality ,welcome to every
customers come to visit and buy ! ! !We will 24 hourse services for
you ,please don't hesitate to contact us when you need.
