5t/8t/10t Hydraulic Decoiler Uncoiler with Coil Car for Metal
Forming Machine5t/8t/10t Hydraulic Decoiler Uncoiler with Coil Car for Metal
Forming Machine is mostly used for metal roll forming production
line or metal sheet cutting line. The fuction of hydraulic decoiler
machine is save labor and make the work more efficiency. For this
decoiler machine, it can support 8 tons metal coil, max width is
1300mm. Usually most of decoilers can be only suitable for 1250mm
width. We adopt 5.5KW electric motor to rotate the shaft, it can
decoil automatically. In a certain, it speed up the whole
production because passive decoiler need to be pulled metal coils
by roll forming machine or cutting machine. Apparently, it is low
speed and dangerous.
1. Diagram of Hydraulic decoiler machine:
2. Technical parameters| Configurations | Hydraulic decoiler, hydraulic station, coil car, car rail |
Material | Raw material | PPGI, GI steel |
| Coil width | Max 1300mm |
Hydraulic Decoiler with coil car | Capacity: 5T/8T/10T/15T |
Expand by hydraulic |
| Single arm to put the coil |
| Expanding range : 600-1400mm |
| Motor power: 5.5 KW/7.5KW |
| Hydraulic power:5.5KW/ 7.5 KW |
| Hydraulic pressure:16Mpa |
| Material of shaft: Gcr45 steel |
| Material of main machine body: 45# H steel |
| Coil car: lifting by hydraulic |
| Lifting height: about 400mm |
| Rail length of coil car: 2.5m (also can customize) |
| Size of decoiler: 2.8m X 3.8m X 2.5m H*L*W |
| Weight of decoiler: about 4.5 tons |
| PLC: Sanjing, famous brand in China |
| Control: Buttons and switches |
| Decoiler color: yellow and blue |
| Voltage: 380V,50HZ,3 Phases (also can customize) |
| No. | Product Name | QTY |
| 1 | 5t/8t/10t Hydraulic Decoiler Uncoiler with Coil Car for Metal
Forming Machine | 1 |
- The structure is simple and the appearance of the machine is
beautiful because we adopt the shape-steel structure and most of
the connectors are screw which make the machine flexible and
stronger.
- All the components of machine are from brand-famous enterprise so
that they ensure the machine normal function very effectively.
- We adopt the automatic length-fixed forming and cutting to
guarantee the length to be precise and the finished product clear
without deforming .
- It is very easy to install the equipment and suitable for producing
in the factory.
- Low noise with high efficiency.
4. Photos of 5T/8T/10T Hydraulic Decoiler Uncoiler with Coil Car
for Metal Forming Machine for Reference:
